1-2 Ton Manual Pallet Stacker

Main Features：
Single frame manual stacker is a king of handing and short-distance transportation tool.
It has the following features, steady lifting, flexible moving, convenient opration, univeral whee has brake device, safe and reliable.
It has reasonable design, compact structure and goodlooking appearance, it's necessary tools for workshop, warehouse, wharf and station.

Product specifications：

Model / Model		IT	1.5T	2T
Rated load	kg	1000	1500	2000
Minimum height of fork	mm	85	85	85
Maximum height of fork	mm	1600	1600	1600
The minimum height of the mast	mm	2080	2080	2080
Fork size	mm	150/160x60	150/160x60	150/160x60
Fork length	mm	1140	1140	1140
Fork width (adjustable)	mm	330~720	330~720	330~720
Turning radius	mm	1380	1380	1380
weight	kg	240	260	300
Fork wheel	mm	Φ74x70	Φ74x70	Φ74x70
Big wheel	mm	Φ180x50	Φ180x50	Φ180x50
Total length	mm	1650	1650	1650
Total width	mm	770	770	770
