| Item | Unit | Specification | |
| Basic parameters | Product number | CDD | |
| Power unit | Battery | ||
| Driving style | Standing Drive | ||
| Rated load | kg | 1000/1500/2000/3500 | |
| Load center | mm | 500 | |
| Tire | Tyre type | Polyurethane | |
| Drive wheel size value (diameter X width) |
mm | Φ 250x80 | |
| Load bearing wheel size (diameter X width) |
mm | Φ 80x70 | |
| Balance wheel size (diameter X width) | mm | Φ 100x50 | |
| Number of drive wheels, balance wheels, load bearing wheels |
1/2/4 | ||
| Basic size | Lifting height | mm | 1600/2000/2500/3000/3500 |
| Whole vehicle height (when the fork is pierced) |
mm | 2050/1580/1830/2080/2330 | |
| Vehicle height (when the fork is the highest) |
mm | 2050/2550/3050/3550/4050 | |
| Height of fork from ground (lowest) | mm | 90 | |
| Vehicle length (pedal expansion / collapse) |
mm | 2400/1900 | |
| Vehicle width | mm | 850 | |
| Fork length | mm | 1100 (Customized accepted) | |
| Maximum adjustable outer width of fork | mm | 680/1000 | |
| Turning radius | mm | 1530 | |
| Performance | Travel speed, full load / no load | km/h | 4.0/6.0 |
| Increase speed, full load / no load | mm/s | 80/130 | |
| Falling speed, full load / no load | mm/s | 110/90 | |
| Gradeability, full load / no load | % | 5/8 | |
| Braking method | Electromagnetic brake | ||
| Drive | Drive motor power | KW | 1.2 |
| Increase motor power | KW | 2.2 | |
| Battery voltage / battery capacity | V/Ah | 24V/120Ah （Option 180Ah/210Ah） | |
