Product Features
1.Standard AC AC drive and EPS electric power steering, better feel and lower energy consumption;
2.Smaller body size with smaller turning radius and right angle stacking channels;
3.With the speed limit function of turning, the automatic deceleration of turning can effectively protect the safety of goods and operators;
4.Ergonomic design: easy to operate valve stem and multi-function intelligent instrument, some models with wheel display function;
5.Advanced Curtis controller, more stable and safer;

Product Specifications

Model		MF10	MF12	MF15D	MF20	MF25	MF30
Power type		Battery	Battery	Battery	Battery	Battery	Battery
Operate type		Stand on	Stand on	Stand on	Stand on	Stand on	Stand on
Service weight（incl.battery）	kg	1750	2000	2100	2750	3300	3400
Load capacity	Q(kg)	1000	1200	1500	2000	2500	3000
Load center	C(mm)	500	500	500	500	500	500
Lift height	h3(mm)	3000	3000	5000	3000	3000	3000
Fork size	l/e/s(mm)	920/100/35	1070/100/35	1070/100/35	1070/100/40	1070/100/45	1070/125/45
Front overhang	x(mm)	130	140	140	180	185	185
Turning radius	Wa(mm)			1580	1784	1995	2192
Max.gradeability	%	8%	10%	10%	10%	10%	10%
Lifting speed,Laden/unladen	mm/s	110/160	150/190	220/320	220/380	240/320	220/320
Lowering speed,Laden/unladen	mm/	210/190	190/170	340/290	310/260	340/290	340/290
