| Standard | |||
| 1.1 | Manufacturer | HITOP | |
| 1.2 | Model | CDD10 | |
| 1.3 | Power Type | Battery | |
| 1.4 | Operation Type | Stand on | |
| 1.5 | Rated Capacity | Q(kg) | 1000 |
| 1.6 | Load Center | C(mm) | 500 |
| 1.8 | Front Overhand | x(mm) | 148 |
| 1.9 | Wheelbase | y(mm) | 1410 |
| Weight | |||
| 2.1 | Service Weight(incl.battery) | kg | 2490 |
| 2.2 | Weight distribution when loaded，drive side/load side | kg | 940/2550 |
| 2.3 | Weight distribution when unloaded，drive side/load side | kg | 1410/1080 |
| Wheel | |||
| 3.1 | Wheel Types | PU | |
| 3.2 | Load Wheel | mm | φ150×90 |
| 3.3 | Drive wheel | mm | φ254×100 |
| 3.4 | Balance wheel | mm | / |
| 3.5 | Number of wheels,,front/rear(x=drive wheel) | 4/1X | |
| 3.6 | Wheel tread,drive side | b10(mm) | / |
| 3.7 | Wheel tread,load side | b11(mm) | 1008 |
| Size | |||
| 4.2 | Mast closed height | h1(mm) | 2300 |
| 4.3 | Lift height | h3(mm) | 2760 |
| 4.4 | Mast extended height | h4(mm) | 5010 |
| 4.5 | Overhead guard height | h6(mm) | 2250 |
| 4.6 | Platform min.ground clearance | h7(mm) | 260 |
| 4.7 | Auxiliary lift height | h9(mm) | 700 |
| 4.8 | Platform max.ground clearance | h12(mm) | 3000 |
| 4.9 | Overall length | l1(mm) | 2825 |
| 4.10 | Length to forkface | l2(mm) | 1755 |
| 4.11 | Overall width | b1/b2(mm) | 1150 |
| 4.12 | Fork size | l/e/s(mm) | 1070/100/40 |
| 4.13 | Fork outside width | b5(mm) | 700 |
| 4.14 | Turning radius | Wa(mm) | 1625 |
