| Model | Unit | CPD35 | |
| Power type | Battery | ||
| Rated load | KG | 3500 | |
| Load center distance | mm | 500 | |
| Driving type | Seat | ||
| Length | With fork L1 | mm | 3664 |
| Without fork L2 | 2570 | ||
| Whole Width B | 1243 | ||
| Height | Overall height (mast lowered) H1 |
2070 | |
| Overall height to overhead guard H2 |
2210 | ||
| Overall height (mast extend) H3 |
4225 | ||
| Distance from seat to top light L3 | 1060 | ||
| Wheel base L4 | 1680 | ||
| Front overhang Y | 490 | ||
| Back overhang L5 | 425 | ||
| Front wheel tread R | 1000 | ||
| Back wheel tread P | 980 | ||
| Min Floor clearance F | 135 | ||
| Max lifting height H | 3000 | ||
| Free lifting height H4 | 160 | ||
| Fork changing S | 1060/250 | ||
| Min Turning radius WA | 2500 | ||
| Min Right angle aisle width RA | 4100 | ||
| Frame angle a/β | （°） | 6°/12° | |
| Max lifting speed without goods | mm/s | 425 | |
| Max lifting speed with full goods | 260 | ||
| Max speed without goods | Km/h | 14 | |
| Max speed with full goods | 12.5 | ||
| Max climbing angle | ％ | ≤15 | |
| Whole weight | Kg | 5600 | |
| Number of wheels | 2x/2 | ||
| Tyre type (Front/Rear) | Solid tyre | ||
| Front Tyre | 28X9-15 | ||
| Rear Tyre | 18x7-8 | ||
| Hand Brake | Hydraulic Pedal | ||
| Brake type | M-Hand | ||
| Battery Volt/ capacity | V/Ah | 80/500 | |
| Driving motor power | Kw | 16.6AC | |
| Oil pump motor power | 13AC | ||
| Container loading plan (numbers) | 20GP | 2 | |
| 40HQ | 5 | ||
